Connectors and Applications

To configure the settings of your checkout flows, you must install Connectors and create Applications.

Connectors

Payment Integration Types

The Payment Integration Types available for an Application depend on the Connector. If both types are available, only one can be active at a time, but you can set both up and switch between them as needed.

Payment Connectors

A payment Connector manages the communication between the merchant, Checkout, and the PSP. By using payment Connectors in your Applications, you can provide your customers with payment methods such as credit cards, Google Pay, and PayPal in your checkout flow.

Gift card Connectors BETA

A gift card Connector manages the communication between the merchant, Checkout, and the gift card management system. By using gift card Connectors in your Applications, you can provide your customers with the option of using gift cards as a payment method in your checkout flow.

Applications

An Application lets you set a specific configuration for Checkout, such as country-specific or brand-specific checkout flows.

Based on your business needs, you can create multiple Applications. For example, if you need different settings for different countries, you can create multiple Applications and set up user agreements, Payment Integrations, and other settings for each country.

• Complete Checkout: you can configure the general settings, activate the discount code functionality, add user agreements, and add Payment Integrations.

• Payment Only: you can configure only the general settings and add Payment Integrations.

You can create Applications of different types for the same Project.

Payment Integrations

Create a Complete Checkout Application

1. In the Merchant Center main menu, select Checkout > Add application.
2. On the Add application page, click Add complete checkout.
3. On the Add application: Complete checkout page, follow these steps:
   1. In the General information section, do the following:
      • In Application name, enter a plain-text name for the Application.
      • In Application key, enter a unique identifier that contains 2-256 alphanumeric characters and special characters _-.
      • Optional: In Application description, enter a plain-text description for the Application.
   2. In the Application settings section, do the following:
      • In Logo URL, enter a valid URL of the logo that will be visible on your checkout page.
      • From Select countries, select the countries where the Application will be available.
      • In Origin URLs:

        • Optional: Click the toggle to allow all URLs to communicate with your Application. This is recommended for test purposes only.

        • In Specified origin URLs, enter the URLs of websites that you want to use the Application. Only the provided URLs can use Checkout.
          URLs must match the following pattern /^(https?:\/\/)?(([a-zA-Z0-9-]+\.)+[a-zA-Z]{2,})\b(?::\d+)?(?!\/)$/i.
          For example, https://www.example.com or https://example.com:8080.
      • In Payment return URL, enter the URL to redirect customers to after they complete the payment.
      • To display the field for entering discount codes on your checkout page, keep the Activation of discount code function toggle in the activated position. Otherwise, deactivate it.
4. Click Save.

5. To add a user agreement, follow these steps:

   1. In the User agreement tab, click Add agreement and do the following:
      • In User agreement name, enter a plain-text name for the user agreement.
      • In User agreement text, enter the text for the user agreement that can include corresponding links (for example, terms and conditions).
      • From User agreement method, select if a mandatory checkbox should be displayed for the user agreement.
   2. Click Save. The order of user agreements in the list will be the same as displayed on your checkout page. To change the order, click Reorder, drag the agreements, and click Save.
   By default, user agreements are deactivated on creation. To activate the user agreement, click the Status toggle.

6. To add a Payment Integration, follow these steps:

   1. In the Payment integrations tab, click Add payment integration and do the following:
      • From Connector, select the payment Connector or gift card Connector that you installed from the Connect marketplace and that you want to use for the Payment Integration.
      • From Specification of the payments integration, select the Payment Integration Type you want to set up. If the selected Connector supports only one Payment Integration Type, the type will be preselected.

      • Depending on the Payment Integration Type, do the following:

        • If you selected Web components:
          • From Payment method, select the payment method that you want to activate.
          • In Payment integration name, enter a name for the Payment Integration. It will be displayed only in the Merchant Center.
          • Optional: In Payment integration conditions via predicates BETA, enter the Payment Integration predicate to determine the conditions for displaying the Payment Integration. Leave the field empty to always display the Payment Integration.
          • Optional: In Payment integration key BETA, enter a unique identifier that contains 2-256 alphanumeric characters and special characters _-. You need this key if you are using the Checkout Transactions API.
          • Click Save. A Payment integration ID BETA is generated automatically. You need this ID if you are using the Checkout Transactions API.
            Also, the first Payment Integration on the list will be the default Payment Integration on your checkout page. To change the order, click Manage order of payment integrations (frontend), drag the Payment Integrations into the desired order, and click Save.
        • If you selected Drop-in BETA:
          • In Drop-in integration name BETA, enter a name for the Payment Integration. It will be displayed only in the Merchant Center
          • Optional: In Payment integration key BETA, enter a unique identifier that contains between 2 and 256 alphanumeric characters and special characters _-. You need this key if you are using the Checkout Transactions API.
          • Click Save. A Payment integration ID BETA is generated automatically. You need this ID if you are using the Checkout Transactions API.
   By default, Payment Integrations are deactivated on creation. To activate the Payment Integration, click the Status toggle.
7. To activate the Application, click the Status toggle.

Create a Payment Only Application

1. In the Merchant Center main menu, select Checkout > Add application.
2. On the Add application page, click Add payment only.
3. On the Add application: Payment only page, follow these steps:
   1. In the General information section, do the following:
      • In Application name, enter a plain-text name for the Application.
      • In Application key, enter a unique identifier that contains 2-256 alphanumeric characters and special characters _-.
      • Optional: In Application description, enter a plain-text description for the Application.
   2. In the Application settings section, do the following:
      • From Select countries, select the countries where the Application will be available.
      • In Origin URLs:

        • Optional: Click the toggle to allow all URLs to communicate with your Application. This is recommended for test purposes only.

        • In Specified origin URLs, enter the URLs of websites that you want to use the Application. Only the provided URLs can use Checkout.
          URLs must match the following pattern /^(https?:\/\/)?(([a-zA-Z0-9-]+\.)+[a-zA-Z]{2,})\b(?::\d+)?(?!\/)$/i.
          For example, https://www.example.com or https://example.com:8080.
4. Click Save.

5. To add a Payment Integration, follow these steps:

   1. In the Payment integrations tab, click Add payment integration and do the following:
      • From Connector, select the payment Connector or gift card Connector that you installed from the Connect marketplace and that you want to use for the Payment Integration.
      • From Specification of the payments integration, select the Payment Integration Type you want to set up. If the selected payment Connector supports only one Payment Integration Type, the type will be preselected.

      • Depending on the Payment Integration Type, do the following:

        • If you selected Web components:
          • From Payment method, select the payment method that you want to activate.
          • In Payment integration name, enter a name for the Payment Integration. It will be displayed only in the Merchant Center.
          • Optional: In Payment integration conditions via predicates BETA, enter the Payment Integration predicate to determine the conditions for displaying the Payment Integration. Leave the field empty to always display the Payment Integration.
          • Optional: In Payment integration key BETA, enter a unique identifier that contains 2-256 alphanumeric characters and special characters _-. You need this key if you are using the Checkout Transactions API.
          • Click Save. A Payment integration ID BETA is generated automatically. You need this ID if you are using the Checkout Transactions API.
            Also, the first Payment Integration on the list will be the default Payment Integration on your checkout page. To change the order, click Manage order of payment integrations (frontend), drag the Payment Integrations into the desired order, and click Save.
        • If you selected Drop-in BETA:
          • In Drop-in integration name BETA, enter a name for the Payment Integration. It will be displayed only in the Merchant Center
          • Optional: In Payment integration key BETA, enter a unique identifier that contains between 2 and 256 alphanumeric characters and special characters _-. You need this key if you are using the Checkout Transactions API.
          • Click Save. A Payment integration ID BETA is generated automatically. You need this ID if you are using the Checkout Transactions API.
   By default, Payment Integrations are deactivated on creation. To activate the Payment Integration, click the Status toggle.
6. To activate the Application, click the Status toggle.

Edit and delete an Application

• To edit an Application, select it and edit the information on the settings page.
• To delete an Application, select it and click the Delete application icon on the settings page.
